IP65 SMD P6 Outdoor Full Color LED Display For Commercial Advertising
Product features
1: LED display have good waterproof and anti-humidity when used.
2: Stable cabinet, stronger without distortion, anti-rust.
3: Synchronously adjust the brightness and color to make the true and exquisite image.
4: High contrast, high refresh rate make the image without any delay, trailing smear.
5: Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
6: Special wooden box package production protect the whole screen system.
Specifications:
| Model No. | NIYAKR-P6 |
| Pixel Pitch | 6mm |
| Module Size | 192*192mm |
| Module Resolution(pixels) | 32*32 |
| Cabinet Size | 768mm×768mm |
| Panel Resolution(pixels) | 128×128 |
| Pixel Configuration(RGB) | SMD 3 in 1 |
| Pixel Density(pixels/㎡) | 27777 |
| Brightness(cd/㎡) | 7000 |
| Best Viewing Distance(m) | 6-50 |
| Average Power Consumption(W/㎡) | 300 |
| Waterproof Level | IP65 |
| Drive Method | 1/8scan |
| LED SPEC | 3535 |
| Viewing Angle | 140°(H)/140°(V) |
| Operating Temperature | –40~100 |
| Video Frame Rate(Hz) | ≥ 60HZ |
| Display Refresh Rate(Hz) | ≥ 1000HZ |
| Grey Level(colors) | 16.7million |
| MTBF | ≥50,000 hours |
| Lifespan | ≥100,000Hours |
| Working Voltage | 220V±15% OR 110V±15% |
| Wavelength | R 620-625 G 520-525 B 470-475 |
| Graphics Card | DVI Graphics card |
| Video Signal | RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
| Control System | LINSN,NovaStar |
After-sale Service
1: 5 years warranty.
2: Lifetime free maintenance and upgrade.
3: Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
4: Customer satisfaction tracking report.
5: Free technician training.
6: Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
7: Special service for big project, such as stadium, exhibitions, squares and so on.
